12545531 Cable, RADOX 4 GKW-AX 1800V M,1x50 mm² ,1 Meter

The 12545531 RADOX 4 GKW-AX 1800V M 1x50 mm² is a high-performance single-core traction cable designed for applications requiring superior flexibility, durability, and high voltage resistance. Manufactured by Huber+Suhner, this cable features RADOX EI 110 insulation on the inner layer and RADOX EI 109 on the outer layer, ensuring excellent fire, chemical, and weather resistance. The stranded tin-plated copper conductor enhances electrical efficiency and mechanical robustness.

It is primarily used for railway and transportation applications where space-saving installation, high-temperature resistance, and safety compliance are essential. The cable's low smoke, zero halogen (LSZH) properties make it an ideal choice for confined environments, reducing toxic emissions in case of fire.

Key Features:

• High Voltage Rating – Rated for 1800V AC / 3000V AC, ensuring reliable performance in high-power applications.
• Superior Durability – Features electron-beam crosslinked insulation, making it resistant to heat, fire, chemicals, and UV exposure.
• Highly Flexible – Stranded tin-plated copper conductor provides exceptional flexibility and ease of installation.
• Railway-Approved – Designed for permanent installation in rail vehicles or other applications requiring resistance to bending stress.
• Halogen-Free & Fire Retardant – Meets EN 45545-2 and NFPA 130 fire safety standards.
• Weather & Chemical Resistant – Outstanding performance in harsh environments, including resistance to ozone, oil, and fuel.

Additional Specifications:

• Type: High Voltage Traction Cable
• Size: 50mm²
• Number of Cores: 1
• Flexibilty: Flexible
• Gauge: 378 Strands of 0.4Mm
