SDR-240-24, Industrial DIN Rail Power Supply – 24V, 10A, 240W

The Mean Well SDR-240-24 is a high-efficiency, industrial-grade AC-DC DIN rail power supply designed to deliver a stable 24V DC output at 10A, providing 240W of continuous power. Housed in a robust metal casing with an ultra-slim width of 63mm, it is optimized for space-constrained industrial environments. The unit features active Power Factor Correction (PFC), enhancing energy efficiency and compliance with global power standards. Its wide input voltage range and high reliability make it ideal for applications such as factory automation, process control, and industrial machinery.

Key Features:

• High Efficiency (up to 94%) – Ensures minimal energy loss and reduced operational costs.
• Active Power Factor Correction (PFC) – Improves power quality and complies with international standards.
• Ultra-Slim Design (63mm Width) – Saves valuable space on DIN rails in control cabinets.
• Wide Input Voltage Range (88 ~ 264VAC) – Supports global AC mains voltages for versatile application.
• Robust Metal Casing – Enhances durability and EMI shielding in industrial environments.
• Built-in DC OK Relay Contact – Provides remote monitoring of power status.

Additional Specifications:

• Type: Industrial DIN Rail Power Supply
• Output Current: 10A
• Output Voltage: 24V
• Output Power: 240W
• Input Votlage: 88V - 264V AC / 124V - 370V DC
