ACS712T-ELCTR-30A-T ,Hall Effect Current Sensor, 30A, 5V Supply

The ACS712T-ELCTR-30A-T is a fully integrated, Hall-effect-based linear current sensor IC with a 2.1kV RMS voltage isolation and low-resistance current conductor. It provides an analog output voltage proportional to AC or DC current, making it ideal for applications in motor control, load detection, switched-mode power supplies, and overcurrent fault protection.

This sensor operates with a 5V supply and offers a bandwidth of 50 kHz. It features an extremely stable output offset voltage and is ratiometric to the supply voltage, delivering consistent performance even under varying conditions.

Key Features :

• 30A max current sensing with ±66 mV/A sensitivity.
• Hall-effect-based current sensing with 5V single supply operation.
• Small footprint SOIC8 package.
• 50 kHz bandwidth with low-noise analog signal path.
• 2.1 kVRMS isolation voltage, suitable for high-voltage applications.
• Factory-trimmed for accuracy, providing a low-offset and linear output.
