TLP523-4,Quad-Channel Photocoupler,DIP-16

The 6N136 Optocoupler is a high-performance photocoupler designed to provide electrical isolation and signal coupling in high-speed digital and analog circuits. Featuring a gallium arsenide infrared LED coupled to a high-gain phototransistor, this optocoupler delivers fast and reliable data transmission at rates up to 1MBd.

With a high isolation voltage of 5000 Vrms and compact DIP-8 packaging, the 6N136 is an ideal solution for space-constrained designs. It supports a wide range of applications, including industrial automation, logic circuits, and power systems, while its wide operating temperature range ensures reliable performance in harsh environments.

The 6N136 is RoHS compliant, ensuring environmentally responsible use while delivering superior performance and durability.

• High-Speed Data Transmission: Supports data rates up to 1MBd, making it ideal for high-speed signal coupling.
• High Isolation Voltage: Rated at 5000 Vrms for superior electrical isolation and safety.
• Phototransistor Output: Provides accurate and reliable signal coupling in digital and analog circuits.
• Compact DIP-8 Package: Ensures easy PCB integration with a standard footprint.
• Wide Operating Temperature Range: Operates effectively between -55C to +100C.
• Versatile Applications: Suitable for industrial automation, logic circuits, and power control systems.
