TLP181GB,Mini Flat Photocoupler,4-Pin,SMD

The MCT2E Optocoupler in a DIP-6 package is a high-performance optical isolator featuring a gallium arsenide infrared LED optically coupled to a silicon NPN phototransistor. It provides high direct-current transfer ratios and robust electrical isolation, making it suitable for industrial, medical, and telecommunications applications. With a high isolation voltage of 3.55 kV and TTL circuit compatibility, this optocoupler ensures efficient and safe data transfer across circuits with different voltage levels. Its plastic encapsulation enhances durability, while the wide operating temperature range supports reliable operation in extreme environments.

This optocoupler is also designed for high-speed switching applications, with typical rise and fall times of 5 µs. Its standard DIP-6 package facilitates easy integration into various designs, and the device is interchangeable with General Instruments MCT2 and MCT2E optocouplers. Whether you need electrical isolation or signal transfer, the MCT2E optocoupler is a reliable choice for your projects.

• Gallium Arsenide Infrared LED: Ensures reliable optical coupling for high-efficiency signal transfer.
• High Isolation Voltage: Withstands up to 3.55 kV for robust electrical isolation.
• Standard DIP-6 Package: Compact and easy to mount for various PCB designs.
• Wide Operating Temperature Range: Functions effectively between -55C and 100C.
• High-Speed Switching: Typical rise and fall times of 5us for fast response.
• TTL Compatibility: Designed for seamless integration with standard TTL integrated circuits.
