MC14066BCP,Quad Bilateral Analog Switch, 3V-18V Supply,PDIP-14

The MC14066BCP is a Quad Bilateral Analog Switch designed for analog and digital signal switching applications. Each switch is independently controlled, allowing seamless bidirectional transmission of signals without distortion.

Operating from a wide voltage range of 3V to 18V, the MC14066BCP supports both low-power and high-performance applications. The low ON resistance (80Ohm typical at 15V) ensures minimal signal degradation, making it ideal for analog multiplexing, modulator/demodulator applications, and general-purpose switching.

With built-in triple diode protection on all control inputs, the MC14066BCP is highly resistant to static discharge and transient voltages. Additionally, its low noise performance (12 nV/√Hz at 1kHz) ensures precision signal switching for high-fidelity audio, sensor applications, and signal processing circuits.

Encased in a PDIP-14 package, the MC14066BCP is well-suited for industrial control, communication systems, and embedded applications requiring reliable analog signal routing.

• Quad Bilateral Analog Switch: Allows bidirectional signal transmission for both analog and digital signals.
• Wide Operating Voltage Range: Functions efficiently from 3V to 18V, ensuring compatibility with various logic families.
• Low ON Resistance: Provides 80Ohm typical ON resistance at 15V, minimizing signal loss.
• Triple Diode Protection: Protects control inputs from static and transient voltages.
• High Signal Integrity: Supports low noise operation (12 nV/√Hz at 1kHz) for precision signal switching.
• Standard PDIP-14 Package: Ensures easy through-hole PCB integration.
