P8049AH, 8-Bit Microcontroller, 11 MHz, 2 KB MROM, 128 Bytes RAM, 40-Pin DIP

The P8049AH is an 8-bit microcontroller developed by Intel Corporation, belonging to the MCS-48 family. Operating at a clock speed of up to 11 MHz, it is designed for a variety of embedded applications requiring reliable performance and efficient resource utilization.

Equipped with 2 KB of Masked ROM (MROM) for program storage and 128 bytes of on-chip RAM for data handling, the P8049AH provides a balanced memory architecture suitable for control-oriented tasks. Its 24 programmable I/O lines offer flexible interfacing capabilities, allowing seamless integration with external peripherals and devices.

The microcontroller features a single 16-bit timer/event counter, supporting accurate timing operations and event management. Additionally, the on-chip oscillator and clock circuitry simplify system design by minimizing the need for external timing components.

Housed in a 40-pin Dual In-Line Package (DIP), the P8049AH is suitable for through-hole mounting, facilitating straightforward integration into various hardware designs.

• High-Performance 8-Bit CPU: Based on the 8048 microcontroller architecture, delivering efficient processing capabilities.
• 2 KB Masked ROM (MROM): Provides non-volatile program storage for embedded applications.
• 128 Bytes of On-Chip RAM: Facilitates efficient data handling and temporary storage.
• 24 Programmable I/O Lines: Offers versatile interfacing options for various peripherals and devices.
• Single 16-Bit Timer/Event Counter: Enables precise timing operations and event counting.
• On-Chip Oscillator and Clock Circuitry: Simplifies system design by reducing the need for external components.
