MDT2010EP, 8-bit EPROM-Based Microcontroller, DIP-18

The MDT2010EP is an 8-bit EPROM-Based Microcontroller designed for embedded systems, industrial automation, and consumer electronics. Built using CMOS technology, this microcontroller ensures low power consumption and high noise immunity.

With a maximum clock frequency of 20MHz, the MDT2010EP enables fast data processing, supporting a 200ns instruction cycle for time-sensitive applications. It features 1K words of EPROM for firmware storage and 32 bytes of RAM for variable storage and processing.

Operating within a wide voltage range of 2.3V to 6.3V, this microcontroller is adaptable to various power environments. It also supports multiple oscillator types, including RC, Low-Frequency, Standard, and High-Frequency Crystals, providing flexibility in system design.

The DIP-18 package makes the MDT2010EP ideal for legacy system upgrades, DIY electronics projects, and industrial control applications requiring reliable, high-speed microcontroller functionality.

• 8-bit Microcontroller: Fully static CMOS design for high-speed performance and power efficiency.
• Clock Frequency: Operates up to 20MHz, with a minimum instruction cycle time of 200ns.
• Wide Supply Voltage Range: Functions between 2.3V and 6.3V, ensuring compatibility with various power sources.
• Memory Configuration: Features 32 bytes of RAM and 1K words of EPROM, suitable for embedded control applications.
• Programmable Oscillator Options: Supports RC, Low-Frequency Crystal, Standard Crystal, and High-Frequency Crystal Oscillators.
• DIP-18 Package: Standard 18-pin Dual In-Line Package for easy integration into through-hole PCB designs.
