TLC7528C,Dual 8-Bit,Multiplying Digital-to-Analog Converter, SOP-24

The TLC7528C is a high-performance dual 8-bit multiplying digital-to-analog converter (DAC) designed for precision analog signal generation in digital systems. With its CMOS technology and advanced architecture, this IC ensures exceptional accuracy and reliability.

The device operates efficiently over a wide supply voltage range of 4.75V to 15.5V, making it ideal for industrial, automotive, and consumer applications. Each DAC has an independent data latch, enabling flexible operation and seamless integration with microprocessor-controlled systems.

Housed in a compact SOP-24 package, the TLC7528C is a versatile solution for applications requiring low power dissipation and high-speed data conversion, such as programmable gain controls, waveform generation, and signal modulation systems.

• Dual DAC Design: Features two independent 8-bit DACs for flexible and efficient analog signal generation.
• High Precision and Stability: Ensures monotonic operation over the entire conversion range with low linearity error.
• Wide Supply Voltage Range: Operates with supply voltages from 4.75V to 15.5V, suitable for diverse applications.
• Integrated Data Latches: On-chip latches simplify microprocessor interface and provide secure data handling.
• Fast Response Time: Settling time of 100 ns ensures quick and reliable signal conversion.
• Compact SOP-24 Package: Easy integration into compact designs for industrial and consumer applications.
