S2055M,Silicon-Controlled Rectifier,TO-220

The S2055M is a high-performance Silicon-Controlled Rectifier (SCR) designed for AC power control and phase control applications. With a 600V peak reverse repetitive voltage (VRRM) and a continuous forward current rating of 20A, it is ideal for applications such as motor speed controls, industrial automation, heating systems, and power tools.

This Thyristor features a low gate trigger voltage (Vgt) of 1.5V and a trigger current (Igt) of 30mA, allowing it to be easily driven by low-power control circuits. Its ability to handle 200A surge currents ensures durability and reliability during high inrush conditions.

The compact TO-220 package offers excellent thermal performance and makes it easy to incorporate into existing designs. The S2055M is widely used in industrial equipment, consumer electronics, and power management systems.

• High Voltage Rating: Rated for a peak reverse repetitive voltage (VRRM) of 600V, ensuring reliable operation in high-power circuits.
• Efficient Current Handling: Capable of handling a continuous forward average current (If) of 20A, ideal for demanding applications.
• Surge Current Handling: Withstands a non-repetitive surge peak on-state current (ITSM) of 200A, ensuring protection during inrush conditions.
• Low Gate Trigger Requirements: Operates with a gate trigger voltage (Vgt) of 1.5V and a gate trigger current (Igt) of 30mA, making it easy to control.
• Compact and Efficient Package: Encased in a TO-220 package, providing excellent thermal management and ease of integration.
• Wide Operating Temperature Range: Operates reliably between -40°C and +125°C, suitable for industrial and commercial environments.
