SPS5161X, Single‑Channel Programmable Switching DC Power Supply, 160 V/7.5 A, 360 W

The Siglent SPS5161X is a precision single-channel programmable switching DC power supply from the SPS5000X series. It delivers up to 360 W of output power with a voltage range of 0–160 V and current capacity of 0–7.5 A. Featuring a high-brightness 2.4‑inch OLED display with a 170° viewing angle, it provides clear real-time monitoring of voltage, current, and waveform. The unit supports constant voltage (CV) and constant current (CC) modes with priority protection, adjustable slew rates, fast transient response (< 1 ms), and includes remote sensing and programmable list-sequence mode (up to 50 steps). With USB, LAN, analog control interfaces, optional GPIB, embedded web-server, and full protective mechanisms (OVP, OCP, LPP, OTP), it’s ideal for demanding lab, industrial, and automated testing environments. Multiple SPS5000X units can be connected in series or parallel for higher voltage/current or power requirements.

Key Features

• Single output channel: 0–160 V, 0–7.5 A, delivering up to 360 W
• High-resolution setting and readback: 1 mV voltage, 1 mA current
• Fast transient recovery (< 1 ms) and adjustable voltage/current slew rates
• List-sequence programming up to 50 steps via front panel or remote interfaces
• Remote voltage sensing and internal discharge function
• Comprehensive protections: CV/CC priority, OVP, OCP, LPP, OTP
