Siglent SNA6022A, 2‑Port Vector Network Analyzer, 100 kHz–13.5 GHz

The Siglent SNA6022A is a high-performance 2-port vector network analyzer covering 100 kHz to 13.5 GHz. It features a large 12.1‑inch touchscreen for intuitive data viewing and supports a wide range of measurements including scattering parameters, time‑domain analysis, differential‑parameter, receiver, and pulse testing. With a dynamic range up to 135 dB, 0.05 dB level resolution, and 1 Hz frequency resolution, it excels in filter design, impedance testing, fixture simulation, and ripple testing. Five sweep modes (Linear, Log, Power, CW‑Time, Segment) and multiple calibration options (SOLT, SOLR, TRL, Enhanced Response) ensure flexible and accurate performance.

Key Features

• Operates from 100 kHz to 13.5 GHz with 1 Hz frequency resolution
• High dynamic range of 135 dB and level resolution of 0.05 dB
• Supports 2-port S-parameter, differential-parameter, time-domain, receiver, limit, ripple, impedance conversion, fixture simulation, and adapter adjustment tests
• Offers five sweep modes: Linear, Log-Frequency, Power-Sweep, CW-Time, and Segment-Sweep
• Includes comprehensive calibration options: SOLT, SOLR, TRL, Response, Enhanced Response
• Features internal bias-tee connections and advanced TDR functionality for time-domain analysis
